Rack mounting | Yes |
Power consumption (max) | 5.9 W |
Power supply included | Yes |
Power source | AC |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
DHCP features | DHCP client |
IGMP snooping | Yes |
SSH/SSL support | Yes |
Operating relative humidity (H-H) | 15 - 95% |
Storage relative humidity (H-H) | 15 - 95% |
Storage temperature (T-T) | -40 - 70 °C |
Operating temperature (T-T) | 0 - 40 °C |
System event log | Yes |
Quality of Service (QoS) support | Yes |
Web-based management | Yes |
Switch layer | L2 |
Switch type | Managed |
Cloud-managed | Yes |
Height | 39.1 mm |
Weight | 770 g |
Width | 173 mm |
Depth | 157 mm |
Half duplex | Yes |
Networking standards | IEEE 802.3 |
Flow control support | Yes |
Auto MDI/MDI-X | Yes |
Link aggregation | Yes |
Port mirroring | Yes |
Auto-negotiation | Yes |
VLAN support | Yes |
10G support | No |
Full duplex | Yes |
Auto-sensing | Yes |
Spanning tree protocol | Yes |
Processor model | ARM Cortex-A9 |
INTERNAL MEMORY | 512 MB |
Fanless | Yes |
Memory type | SDRAM |
Flash Memory | 256 MB |
Processor frequency | 800 MHz |
Built-in processor | Yes |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 8 |
Harmonized System (HS) code | 85176990 |
Jumbo frames | 9216 |
Latency (10-100 Mbps) | 5.2 µs |
MAC Address Table | 8000 entries |
Packet buffer memory | 1.5 MB |
Throughput | 11.9 Mpps |
Latency (1 Gbps) | 2.8 µs |
Switching capacity | 16 Gbit/s |
Jumbo Frames support | Yes |
Power Over Ethernet (PoE) | No |
Warnings | Do not open the case or try to repair it yourself. |
