management functions | |
Switch-Typ | Managed |
switch level | L2/L3 |
Eigenschaft | LED-Anzeigen |
connections and interfaces | |
Quantity of module slots SFP+ | 10 |
power plug | AC-Eingangsbuchse |
network | |
mesh standard | IEEE 802.1p, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3z |
Ethernet LAN data transfer rates | 1000,2500,5000,10000 Mbit/s |
Number of VLANs | 4000 |
data transmission | |
Routing/Switching Capacity | 240 Gbit/s |
Transferrate | 178,5 Mpps |
MAC-Adressentabelle | 16000 Eintragungen |
Jumbo-Frames | 12000 |
Data packet buffer memory | 2 MB |
safety | |
DHCP functions | DHCP client, DHCP relay |
Supported security algorithms | HTTPS, SHA-2, SSL/TLS |
multicast capabilities | |
Design | |
Product color | Schwarz |
Services | |
storage capacity | 256 MB |
Flash memory | 32 MB |
energy | |
energy source | AC |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Power consumption (max.) | 24,9 W |
operating conditions | |
operating temperatur | -20 - 50 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 5 - 95% |
humidity during storage | 5 - 95% |
heat dissipation | 84,91 BTU/h |
weight and dimensions | |
broad | 484 mm |
depth | 337 mm |
height | 79 mm |
Weight | 3,63 kg |
logistic data | |
Goods tariff number (HS) | 85176990 |
