management functions | |
Switch-Typ | Managed |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 24 |
Basic Switching RJ-45 Ethernet Ports-Typ | 2.5G Ethernet (100/1000/2500) |
Quantity of module slots SFP+ | 2 |
console port | RJ-45 |
network | |
mesh standard | IEEE 802.3af, IEEE 802.3at |
Eigenschaft | Power over Ethernet (PoE) |
Ethernet LAN data transfer rates | 10,100,1000,5000 Mbit/s |
data transmission | |
Routing/Switching Capacity | 124 Gbit/s |
throughput | 62 Gbit/s |
Transferrate | 92,25 Mpps |
Design | |
Product color | Weiß |
housing material | Stahl |
energy | |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
DC input voltage | 52 V |
input current | 8.5 A |
Power consumption (standard operation) | 34,2 W |
Power consumption (max.) | 550 W |
Power Over Ethernet (PoE) | |
Power over Ethernet (PoE) type supported | Active PoE |
Power over Ethernet (PoE) performance per port | 34,2 W |
operating conditions | |
operating temperatur | -5 - 40 °C |
Operating relative humidity | 10 - 95% |
weight and dimensions | |
broad | 442,2 mm |
depth | 325 mm |
height | 43,7 mm |
Weight | 5,2 kg |
certificates | |
certification | CE, FCC, IC |
logistic data | |
Goods tariff number (HS) | 85176990 |
