management functions | |
Switch-Typ | Managed |
switch level | L3 |
Eigenschaft | Netzteil enthalten |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 24 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Quantity of SFP module slots | 4 |
network | |
mesh standard | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3x |
data transmission | |
Routing/Switching Capacity | 56 Gbit/s |
passage | 41,6 Mpps |
MAC-Adressentabelle | 8192 Eintragungen |
Latency (1Gbps) | 1,5 µs |
Data packet buffer memory | 12,38 MB |
safety | |
DHCP functions | DHCP client |
authentication | MAC-basierte Authentifizierung |
multicast capabilities | |
logs | |
IPv4 & IPv6 features | IPv4/IPv6 access-control list (ACL) |
IPv4 FIB entries | 256 |
IPv6 FIB entries | 128 |
Design | |
form factor | 1U |
Services | |
processor | ARM Cortex-A9 |
processor clock speed | 1016 MHz |
storage type | DDR3-SDRAM |
storage capacity | 8192 MB |
Flash memory | 16384 MB |
energy | |
energy source | AC |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Power consumption (max.) | 33 W |
operating conditions | |
operating temperatur | 0 - 45 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 15 - 95% |
humidity during storage | 15 - 90% |
weight and dimensions | |
broad | 442 mm |
depth | 201 mm |
height | 44 mm |
Weight | 2,6 kg |
logistic data | |
Goods tariff number (HS) | 85176990 |
