management functions | |
Switch-Typ | Managed |
switch level | L2/L2+ |
Eigenschaft | Power over Ethernet (PoE) |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 24 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Quantity of SFP module slots | 4 |
network | |
mesh standard | IEEE 802.3af, IEEE 802.3at |
Virtual LAN functions | MAC address-based VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN |
Number of VLANs | 4000 |
data transmission | |
Routing/Switching Capacity | 56 Gbit/s |
Transferrate | 41,66 Mpps |
MAC-Adressentabelle | 8000 Eintragungen |
Jumbo-Frames | 9000 |
Data packet buffer memory | 4,1 MB |
safety | |
DHCP functions | DHCP relay, DHCP server |
multicast capabilities | |
Design | |
Product color | Grau |
Services | |
energy | |
energy source | AC/PoE |
AC input voltage | 100 - 240 V |
AC input frequency | 50/60 Hz |
Power consumption (max.) | 184,7 W |
Power Over Ethernet (PoE) | |
Number of Power over Ethernet plus (PoE+) ports | 16 |
Power over Ethernet (PoE) performance per port | 30 W |
Overall Power over Ethernet (PoE) | 150 W |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 90% |
heat dissipation | 628 BTU/h |
weight and dimensions | |
broad | 440 mm |
depth | 220 mm |
height | 44 mm |
