management functions | |
Switch-Typ | Managed |
switch level | L2 |
Eigenschaft | Rackmontageset |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 24 |
Basic Switching RJ-45 Ethernet Ports-Typ | Fast Ethernet (10/100) |
Fast Ethernet (copper) ports | 24 |
Number of Gigabit Ethernet (copper) ports | 4 |
Number of combo SPF ports | 2 |
network | |
Copper Ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
supported cable types | Cat5, Cat5e |
Number of VLANs | 512 |
data transmission | |
Routing/Switching Capacity | 12,8 Gbit/s |
passage | 9,5 Mpps |
MAC-Adressentabelle | 8000 Eintragungen |
number of queues | 4 |
Jumbo-Frames | 9000 |
Data packet buffer memory | 4,1 MB |
safety | |
Supported security algorithms | SNMPv2, SNMPv3, SSH, SSH-2, SSL/TLS |
multicast capabilities | |
logs | |
management logs | SNMP v1/v2c/v3, RMON, SNTP, TFTP |
Design | |
form factor | 1U |
Product color | Schwarz |
number of fans | 2 Lüfter |
certification | CE, FCC, RoHS |
Services | |
Compatible operating systems | Microsoft Windows XP, Vista, Windows 7, Windows 8, MAC OS, NetWare, UNIX, Linux |
energy | |
energy source | AC |
AC input voltage | 100 - 240 V |
AC input frequency | 50/60 Hz |
Power consumption (max.) | 291,6 W |
Power Over Ethernet (PoE) | |
Number of Power over Ethernet plus (PoE+) ports | 24 |
Overall Power over Ethernet (PoE) | 250 W |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 90% |
heat dissipation | 995,09 BTU/h |
weight and dimensions | |
broad | 440 mm |
depth | 180 mm |
height | 44 mm |
Supplied cables | AC |
