management functions | |
Switch-Typ | Managed |
Eigenschaft | Rackmontageset |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 24 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Number of combo SPF ports | 4 |
Optical cable connector | SFP |
network | |
Copper Ethernet cabling technology | 100BASE-TX, 1000BASE-T |
Virtual LAN functions | Private VLAN, Voice VLAN, Protocol-based VLAN, MAC address-based VLAN, Port-based VLAN, IP subnet–based VLAN |
optical fiber | |
Ethernet cable cabling technology | 1000BASE-X |
data transmission | |
Routing/Switching Capacity | 56 Gbit/s |
Transferrate | 42 Mpps |
MAC-Adressentabelle | 16000 Eintragungen |
Data packet buffer memory | 1,5 MB |
safety | LVD, BSMI |
DHCP functions | DHCP snooping, DHCP relay, DHCPv6 relay, DHCP client |
Supported security algorithms | 802.1x RADIUS, SNMP, SNMPv3 |
authentication | Gast VLAN, Port-basierte Authentifizierung |
authentication type | IEEE 802.1x, RADIUS |
Queue Scheduling Algorithms | SPQ, WFQ, Weighted Round Robin (WRR) |
multicast capabilities | |
Design | |
Product color | Schwarz |
Electromagnetic compatibility | FCC 15 A, CE A, BSMI EMC |
certification | RoHS |
Services | |
storage capacity | 256 MB |
Flash memory | 32 MB |
noise level | 27,2 dB |
Mean Time Between Failures (MTBF) | 638691 h |
energy | |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Power consumption (max.) | 463,5 W |
Power Over Ethernet (PoE) | |
Number of Power over Ethernet (PoE) ports | 24 |
Overall Power over Ethernet (PoE) | 375 W |
operating conditions | |
operating temperatur | 0 - 50 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 95% |
humidity during storage | 10 - 95% |
heat dissipation | 1580,54 BTU/h |
weight and dimensions | |
broad | 441 mm |
depth | 270 mm |
height | 44 mm |
Weight | 3,8 kg |
Supplied cables | AC |
package weight | 4,97 kg |
logistic data | |
Goods tariff number (HS) | 85176990 |
