management functions | |
Switch-Typ | Managed |
switch level | L3 |
Eigenschaft | Rackmontageset |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 24 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Quantity of module slots SFP+ | 4 |
network | |
Virtual LAN functions | Tagged VLAN |
Number of VLANs | 4000 |
data transmission | |
Routing/Switching Capacity | 128 Gbit/s |
throughput | 64 Gbit/s |
Transferrate | 95,232 Mpps |
MAC-Adressentabelle | 16000 Eintragungen |
Data packet buffer memory | 12 MB |
safety | |
DHCP functions | DHCP Option 82, DHCP relay, DHCP server, DHCP snooping |
Zugriffskontrollliste (ACL) IPv4-Einträge | 2000 |
Zugriffskontrollliste (ACL) IPv6-Einträge | 2000 |
Supported security algorithms | 802.1x RADIUS, SNMP |
authentication type | AAA, RADIUS, TACACS+ |
Queue Scheduling Algorithms | SP, WFQ, WFQ+SP, WRR+SP, Weighted Round Robin (WRR) |
logs | |
Design | |
Product color | Grau |
energy | |
energy source | AC |
input current | 5 A |
input voltage | 12 V |
Power consumption (standard operation) | 60 W |
operating conditions | |
operating temperatur | 0 - 45 °C |
Storage temperature range | -10 - 60 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 95% |
weight and dimensions | |
broad | 200 mm |
depth | 440 mm |
height | 44 mm |
Weight | 2,94 kg |
Supplied cables | AC |
