management functions | |
Switch-Typ | Unmanaged |
Eigenschaft | Betriebsanleitung |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 24 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
network | |
mesh standard | IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
supported cable types | Cat5 |
data transmission | |
Routing/Switching Capacity | 48 Gbit/s |
MAC-Adressentabelle | 8000 Eintragungen |
Latency (1Gbps) | 4,7 µs |
Jumbo-Frames | 9216 |
Packet water supply system (1 Gbit / s) | 1448000 pps |
Data packet buffer memory | 0,512 MB |
Design | |
Product color | Schwarz |
housing material | Metall |
LED indicators | Aktivität, Link, Leistung, Geschwindigkeit |
Services | |
Mean Time Between Failures (MTBF) | 620798 h |
energy | |
AC input voltage | 110 - 240 V |
AC input frequency | 50 - 60 Hz |
input current | 1 A |
Power consumption (max.) | 11,1 W |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -20 - 70 °C |
Operating relative humidity | 0 - 90% |
humidity during storage | 0 - 95% |
operating height | 0 - 3000 m |
heat dissipation | 37,96 BTU/h |
weight and dimensions | |
broad | 252 mm |
depth | 180 mm |
height | 44 mm |
Weight | 1,31 kg |
scope of delivery | |
Supplied cables | AC |
certificates | |
certification | CE Mark, FCC 15 A, IC A, RCM, CCC, VCCI, KC, CB, CE LVD |
logistic data | |
Goods tariff number (HS) | 85176990 |
