management functions | |
Switch-Typ | Unmanaged |
Eigenschaft | Rackmontageset |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 24 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Number of Gigabit Ethernet (copper) ports | 24 |
power plug | DC-Anschluss |
network | |
mesh standard | IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
supported cable types | Cat3, Cat4, Cat5, Cat5e |
data transmission | |
data rate | 10/100/100 Mbps |
Routing/Switching Capacity | 48 Gbit/s |
Transferrate | 35,7 Mpps |
MAC-Adressentabelle | 8000 Eintragungen |
Max. data transfer rate | 1 Gbit/s |
Jumbo-Frames | 10000 |
logs | |
Supported network protocols | CSMA/CD, TCP/IP |
Design | |
Product color | Grau |
energy | |
energy source | AC |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Power consumption (max.) | 13,62 W |
Other functions | |
Dimensions (WxDxH) | 294 x 180 x 44 mm |
transmission technology | Kabelgebunden |
bandwidth | 48 Gbit/s |
energy demand | 100 - 240V, 50/60Hz |
network functions | Gigabit Ethernet |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 90% |
temperature operating environment | 32 - 104 °F |
heat dissipation | 46,44 BTU/h |
weight and dimensions | |
broad | 294 mm |
depth | 180 mm |
height | 44 mm |
scope of delivery | |
Supplied cables | AC |
packaging type | Box |
package weight | 1,95 kg |
certificates | |
certification | FCC, CE, RoHS |
logistic data | |
Goods tariff number (HS) | 85176990 |
