management functions | |
Switch-Typ | Managed |
switch level | L2/L3/L4 |
Eigenschaft | Netzteil enthalten |
connections and interfaces | |
Number of 10G Ethernet (copper) ports | 24 |
Quantity of module slots SFP+ | 4 |
network | |
Routing inputs | 64 |
IPv4-Routen | 64 |
IPv6-Routen | 32 |
Number of VLANs | 512 |
data transmission | |
Routing/Switching Capacity | 560 Gbit/s |
MAC-Adressentabelle | 16000 Eintragungen |
number of queues | 8 |
Jumbo-Frames | 9000 |
Data packet buffer memory | 4 MB |
safety | |
DHCP functions | DHCP client, DHCP server, DHCP snooping, DHCPv6 relay, DHCPv6 server |
Zugriffskontrollliste (ACL) IPv6-Einträge | 100 |
Supported security algorithms | 802.1x RADIUS, EAP |
authentication type | RADIUS |
multicast capabilities | |
Multicast Listener Discovery (MLD) snooping | MLD snooping support (v1 and v2) |
logs | |
Design | |
Product color | Grau |
number of fans | 3 Lüfter |
Services | |
processor clock speed | 1250 MHz |
storage type | RAM |
storage capacity | 1000 MB |
Flash memory | 256 MB |
noise level | 29,61 dB |
Mean Time Between Failures (MTBF) | 408354,7 h |
energy | |
energy source | AC |
Power consumption (max.) | 92,5 W |
operating conditions | |
operating temperatur | 0 - 50 °C |
Storage temperature range | -20 - 70 °C |
Operating relative humidity | 0 - 95% |
humidity during storage | 0 - 95% |
operating height | 0 - 3000 m |
heat dissipation | 315,66 BTU/h |
weight and dimensions | |
broad | 400 mm |
depth | 204 mm |
height | 43,2 mm |
Weight | 3,38 kg |
