management functions | |
Switch-Typ | Unmanaged |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 5 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Quantity of SFP module slots | 2 |
network | |
mesh standard | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
Copper Ethernet cabling technology | 10BASE-T, 10GBASE-T, 100BASE-TX, 100BASE-T, 1000BASE-T, 1000BASE-TX |
supported cable types | Cat5e |
Eigenschaft | Power over Ethernet (PoE) |
data transmission | |
Routing/Switching Capacity | 12 Gbit/s |
MAC-Adressentabelle | 1000 Eintragungen |
Jumbo-Frames | 9000 |
Design | |
Product color | Schwarz |
housing material | Metall |
International degree of protection (IP code) | IP30 |
safety | IEC EN60950-1 |
certification | CE, FCC, VCCI |
Services | |
buffer size | 1000 KB |
Mean Time Between Failures (MTBF) | 510,304 h |
energy | |
input current | 1 A |
input voltage | 12 - 56 V |
Power consumption (standard operation) | 5,76 W |
Power consumption (max.) | 126 W |
Power Over Ethernet (PoE) | |
Power over Ethernet (PoE) performance per port | 30 W |
operating conditions | |
operating temperatur | -40 - 75 °C |
Storage temperature range | -40 - 85 °C |
Operating relative humidity | 5 - 95% |
weight and dimensions | |
broad | 142 mm |
depth | 105 mm |
height | 43 mm |
