management functions | |
Switch-Typ | Managed |
switch level | L2+ |
Eigenschaft | Power over Ethernet (PoE) |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 48 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Quantity of module slots SFP+ | 2 |
network | |
data transmission | |
Routing/Switching Capacity | 176 Gbit/s |
passage | 131 Mpps |
MAC-Adressentabelle | 16000 Eintragungen |
Latency (10-100Mbps) | 4,4 µs |
Latency (1Gbps) | 2,2 µs |
Latency (10 Gbps) | 1,1 µs |
safety | |
DHCP functions | DHCP snooping |
authentication | Port-basierte Authentifizierung |
authentication type | RADIUS |
multicast capabilities | |
logs | |
IPv4 & IPv6 features | IPv4/IPv6 access-control list (ACL) |
IPv4 FIB entries | 32 |
IPv6 FIB entries | 32 |
Design | |
form factor | 1U |
Product color | Weiß |
Services | |
Physical Stacking (Units) | 4 |
processor | ARM Cortex-A9 |
processor clock speed | 800 MHz |
energy | |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Power Over Ethernet (PoE) | |
Overall Power over Ethernet (PoE) | 600 W |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 15 - 95% |
humidity during storage | 15 - 90% |
weight and dimensions | |
broad | 402,1 mm |
depth | 443 mm |
height | 44 mm |
Weight | 6 kg |
logistic data | |
Goods tariff number (HS) | 85176990 |
