management functions | |
Switch-Typ | Managed |
switch level | L2+ |
Eigenschaft | Schnellstartübersicht |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 48 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Quantity of module slots SFP+ | 4 |
console port | RJ-45/Micro-USB |
power plug | AC-Eingangsbuchse |
network | |
mesh standard | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3z |
data transmission | |
Routing/Switching Capacity | 176 Gbit/s |
Transferrate | 130,9 Mpps |
MAC-Adressentabelle | 16000 Eintragungen |
Jumbo-Frames | 9000 |
Data packet buffer memory | 12 MB |
safety | |
DHCP functions | DHCP client, DHCP relay, DHCP server |
authentication | Auto VLAN, Gast VLAN |
multicast capabilities | |
Design | |
form factor | 1U |
Product color | Schwarz |
number of fans | 3 Lüfter |
energy | |
energy source | AC |
AC input voltage | 100 - 240 V |
AC input frequency | 50/60 Hz |
Power consumption (max.) | 635,7 W |
Power Over Ethernet (PoE) | |
Number of Power over Ethernet plus (PoE+) ports | 48 |
Power over Ethernet (PoE) performance per port | 30 W |
Overall Power over Ethernet (PoE) | 500 W |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 90% |
heat dissipation | 2169,2 BTU/h |
weight and dimensions | |
broad | 440 mm |
depth | 330 mm |
height | 44 mm |
scope of delivery | |
Supplied cables | AC |
certificates | |
certification | CE, FCC, RoHS |
