management functions | |
Switch-Typ | Unmanaged |
Eigenschaft | Plug & Play |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 48 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
power plug | DC-Anschluss |
network | |
mesh standard | IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
Ethernet LAN data transfer rates | 10,100,1000 Mbit/s |
data transmission | |
Routing/Switching Capacity | 96 Gbit/s |
MAC-Adressentabelle | 16000 Eintragungen |
Latency (1Gbps) | 4 µs |
Jumbo-Frames | 9216 |
Packet water supply system (1 Gbit / s) | 1448000 pps |
Design | |
form factor | 1U |
Product color | Schwarz |
LED indicators | Aktivität, Link, Leistung |
Services | |
energy | |
energy source | AC |
AC input voltage | 110 - 240 V |
AC input frequency | 50 - 60 Hz |
input current | 1 A |
Power consumption (standard operation) | 8,81 W |
Power consumption (max.) | 23 W |
operating conditions | |
operating temperatur | 0 - 50 °C |
Storage temperature range | -20 - 70 °C |
heat dissipation | 7866 BTU/h |
weight and dimensions | |
broad | 440 mm |
depth | 204 mm |
height | 43,2 mm |
Weight | 3,15 kg |
logistic data | |
Goods tariff number (HS) | 85176990 |
