connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 4 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
network | |
mesh standard | IEEE 802.3, IEEE 802.3az, IEEE 802.3u |
Eigenschaft | Power over Ethernet (PoE) |
Ethernet LAN data transfer rates | 10,100,1000 Mbit/s |
data transmission | |
Routing/Switching Capacity | 8 Gbit/s |
MAC-Adressentabelle | 2000 Eintragungen |
Jumbo-Frames | 9216 |
Data packet buffer memory | 0,128 MB |
Design | |
Product color | Schwarz |
housing material | Aluminium |
LED indicators | Leistung, Status |
International degree of protection (IP code) | IP30 |
certification | CE, REACH, RoHS, WEEE, UKCA, FCC, IC, CB, RCM |
energy | |
energy source | AC/DC |
DC input voltage | 7 - 57 V |
input voltage | 9 - 40 V |
Power consumption (standard operation) | 0,26 W |
Power consumption (max.) | 1,44 W |
Power Over Ethernet (PoE) | |
Power over Ethernet (PoE) type supported | Passive PoE |
operating conditions | |
operating temperatur | -40 - 75 °C |
Operating relative humidity | 10 - 90% |
weight and dimensions | |
broad | 102 mm |
depth | 81,5 mm |
height | 25 mm |
Weight | 210 g |
