management functions | |
Switch-Typ | Unmanaged |
switch level | L2 |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 5 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
power plug | DC-Anschluss |
network | |
mesh standard | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x |
data transmission | |
passage | 14,88 Mpps |
MAC-Adressentabelle | 4000 Eintragungen |
Eigenschaft | Power over Ethernet (PoE) |
Design | |
Product color | Schwarz |
certification | FCC, CE |
Services | |
buffer size | 128 KB |
energy | |
DC input voltage | 48 V |
Power consumption (standard operation) | 25 W |
Power consumption (max.) | 36 W |
Power Over Ethernet (PoE) | |
Number of Power over Ethernet (PoE) ports | 1 |
Overall Power over Ethernet (PoE) | 36 W |
operating conditions | |
operating temperatur | 0 - 50 °C |
Storage temperature range | -20 - 90 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 10 - 90% |
weight and dimensions | |
broad | 85 mm |
depth | 26 mm |
height | 150 mm |
Weight | 352 g |
