management functions | |
Switch-Typ | Managed |
switch level | L2 |
Eigenschaft | AC-Netzadapter |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 5 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Number of Gigabit Ethernet (copper) ports | 5 |
network | |
mesh standard | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u |
Copper Ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
Virtual LAN functions | Tagged VLAN |
data transmission | |
MAC-Adressentabelle | 2048 Eintragungen |
Jumbo-Frames | 9216 |
Data packet buffer memory | 0,125 MB |
safety | |
Design | |
Product color | Schwarz |
housing material | Metall |
certification | CE FCC EMI class B, ROHS |
energy | |
AC input voltage | 100 - 240 V |
output voltage | 55 V |
output current | 1,3 A |
Power consumption (standard operation) | 3 W |
Power Over Ethernet (PoE) | |
Number of Power over Ethernet plus (PoE+) ports | 4 |
Power over Ethernet (PoE) performance per port | 30 W |
Overall Power over Ethernet (PoE) | 70 W |
operating conditions | |
operating temperatur | 0 - 50 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 90% |
weight and dimensions | |
broad | 193 mm |
depth | 84 mm |
height | 26 mm |
