management functions | |
Switch-Typ | Unmanaged |
Eigenschaft | Netzteil enthalten |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 5 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
network | |
mesh standard | IEEE 802.1p, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3aq, IEEE 802.3at, IEEE 802.3bz, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
Ethernet LAN data transfer rates | 10 Mbit/s |
data transmission | |
Routing/Switching Capacity | 10 Gbit/s |
MAC-Adressentabelle | 2 Eintragungen |
Jumbo-Frames | 9000 |
safety | |
multicast capabilities | |
Design | |
Product color | Schwarz |
housing material | Kunststoff |
LED indicators | Aktivität, Leistung |
energy | |
energy source | Gleichstrom |
DC input voltage | 5 V |
input current | 0.6 A |
Power consumption (max.) | 1,7 W |
Power Over Ethernet (PoE) | |
Overall Power over Ethernet (PoE) | 60 W |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -20 - 60 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 10 - 90% |
weight and dimensions | |
broad | 65 mm |
depth | 120 mm |
height | 24,5 mm |
Weight | 100 g |
package weight | 250 g |
certificates | |
certification | FCC, CE, RCM, IC, UKCA |
