management functions | |
Switch-Typ | Managed |
Eigenschaft | Nachhaltigkeitskonformität |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 5 |
Basic Switching RJ-45 Ethernet Ports-Typ | Fast Ethernet (10/100) |
Fast Ethernet (copper) ports | 5 |
power plug | DC-Anschluss |
network | |
mesh standard | IEEE 802.3u, IEEE 802.3x |
Copper Ethernet cabling technology | 10BASE-T, 100BASE-T |
Ethernet LAN data transfer rates | 10,100 Mbit/s |
data transmission | |
Routing/Switching Capacity | 1,6 Gbit/s |
MAC-Adressentabelle | 1000 Eintragungen |
logs | |
Supported network protocols | CSMA/CD, TCP/IP |
Design | |
Product color | Weiß |
Services | |
energy | |
energy source | Gleichstrom |
AC input voltage | 220 V |
AC input frequency | 50 Hz |
DC input voltage | 5 V |
input current | 0.6 A |
Power consumption (standard operation) | 1,87 W |
Power consumption (max.) | 1,87 W |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 90% |
heat dissipation | 6,38 BTU/h |
weight and dimensions | |
broad | 103,5 mm |
depth | 70 mm |
height | 22 mm |
scope of delivery | |
Supplied cables | AC |
packaging type | Box |
package weight | 190 g |
sustainability | |
certificates | |
Konformitätsbescheinigungen | CE, Eidgenössische Kommunikationskommission (FCC), RoHS |
certification | FCC, RoHs |
