management functions | |
Switch-Typ | Managed |
switch level | L2 |
Eigenschaft | Rackmontageset |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 5 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Number of Gigabit Ethernet (copper) ports | 5 |
network | |
mesh standard | IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
Copper Ethernet cabling technology | 1000BASE-T, 100BASE-TX, 10BASE-T |
supported cable types | Cat3, Cat4, Cat5, Cat5e, Cat6 |
Virtual LAN functions | Port-based VLAN |
Number of VLANs | 32 |
data transmission | |
Routing/Switching Capacity | 10 Gbit/s |
Transferrate | 7,44 Mpps |
MAC-Adressentabelle | 2000 Eintragungen |
Jumbo-Frames | 16000 |
Data packet buffer memory | 1 MB |
safety | |
Design | |
Product color | Schwarz |
certification | FCC, CE, RoHS |
Services | |
Compatible operating systems | Microsoft Windows XP, Vista Windows 7, Windows 8, MAC OS, NetWare, UNIX / Linux |
energy | |
energy source | Gleichstrom |
input current | 0.6 A |
input voltage | 5 V |
Power consumption (max.) | 2,82 W |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 90% |
heat dissipation | 9,07 BTU/h |
weight and dimensions | |
broad | 100 mm |
depth | 98 mm |
height | 25 mm |
Supplied cables | AC |
packaging type | Box |
package weight | 450 g |
