management functions | |
Switch-Typ | Managed |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 5 |
Basic Switching RJ-45 Ethernet Ports-Typ | 2.5G Ethernet (100/1000/2500) |
Number of 2.5G Ethernet (copper) ports | 5 |
USB Type-C Number of ports | 1 |
power plug | USB |
network | |
Copper Ethernet cabling technology | 2.5GBASE-T |
Eigenschaft | AC-Netzadapter |
data transmission | |
Routing/Switching Capacity | 25 Gbit/s |
throughput | 12,5 Gbit/s |
Transferrate | 18,6 Mpps |
multicast capabilities | |
Design | |
form factor | Desktop |
Product color | Weiß |
housing material | Polycarbonat (PC) |
LED indicators | Aktivität, Leistung, Fortschritt |
Services | |
Minimum system requirements | UniFi Network Version 8.4.62 and later |
energy | |
energy source | AC/DC/PoE |
DC input voltage | 5 V |
input current | 1 A |
Power consumption (max.) | 5 W |
power plug type | Typ A |
Power Over Ethernet (PoE) | |
Power over Ethernet (PoE) voltage | 57 V |
Power over Ethernet (PoE) performance per port | 6,4 W |
Other functions | |
network functions | STP / RSTP with priorities and port-level disable, Egress rate limit |
operating conditions | |
operating temperatur | -20 - 45 °C |
Operating relative humidity | 10 - 90% |
weight and dimensions | |
broad | 117,1 mm |
depth | 90 mm |
height | 21,2 mm |
Weight | 206 g |
certificates | |
Konformitätsbescheinigungen | CE, Eidgenössische Kommunikationskommission (FCC), Industry Canada (IC) |
certification | CE, FCC, IC |
