management functions | |
Switch-Typ | Managed |
switch level | L2+ |
Eigenschaft | Rackmontageset |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 8 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Number of installed SFP modules | 2 |
network | |
mesh standard | IEEE 802.3ab, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
Ethernet LAN data transfer rates | 10,100,1000 Mbit/s |
Number of VLANs | 4000 |
data transmission | |
Routing/Switching Capacity | 20 Gbit/s |
throughput | 10 Gbit/s |
Transferrate | 14,88 Mpps |
Number of static routes | 8000 |
safety | |
DHCP functions | DHCP relay, DHCP server, DHCP snooping, DHCPv6 snooping |
Access Control List (ACL) Regeln | 1500 |
authentication type | IEEE 802.1x |
multicast capabilities | Multicast-Weiterleitung |
Design | |
Product color | Schwarz |
energy | |
energy source | AC |
Power consumption (standard operation) | 30 W |
weight and dimensions | |
broad | 175 mm |
depth | 30 mm |
height | 44 mm |
Weight | 1,8 kg |
scope of delivery | |
Supplied cables | AC |
