management functions | |
Switch-Typ | Managed |
switch level | L2 |
Eigenschaft | Ventilatorlos |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 10 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
network | |
Copper Ethernet cabling technology | 10BASE-TX, 1000BASE-T |
Virtual LAN functions | Port-based VLAN, Private VLAN, Protocol-based VLAN, Voice VLAN |
data transmission | |
Routing/Switching Capacity | 20 Gbit/s |
Transferrate | 15 Mpps |
MAC-Adressentabelle | 16000 Eintragungen |
Data packet buffer memory | 1,5 MB |
safety | |
DHCP functions | DHCP client, DHCP relay, DHCP snooping, DHCPv6 client, DHCPv6 relay |
Supported security algorithms | SNMP, SNMPv2, SNMPv3, SSH-2, SSL/TLS |
authentication | Gast VLAN, MAC-basierte Authentifizierung |
authentication type | IEEE 802.1x, RADIUS |
multicast capabilities | |
Design | |
Product color | Schwarz |
certification | LVD, BSMIFCC 15 A, CE EMC A, BSMI ENCRoHS A |
Services | |
storage capacity | 256 MB |
Flash memory | 32 MB |
Mean Time Between Failures (MTBF) | 1213492 h |
energy | |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Power consumption (max.) | 11 W |
operating conditions | |
operating temperatur | 0 - 50 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 95% |
humidity during storage | 10 - 95% |
heat dissipation | 37,51 BTU/h |
weight and dimensions | |
broad | 267 mm |
depth | 162 mm |
height | 44 mm |
Weight | 1,3 kg |
Supplied cables | AC |
package weight | 2,21 kg |
logistic data | |
Goods tariff number (HS) | 85176990 |
