connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 10 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Anzahl der Uplink-Ports | 2 |
power plug | AC-Eingangsbuchse |
network | |
mesh standard | IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x |
Ethernet LAN data transfer rates | 10,100,1000 Mbit/s |
Eigenschaft | Power over Ethernet (PoE) |
data transmission | |
MAC-Adressentabelle | 2000 Eintragungen |
Data packet buffer memory | 0,25 MB |
Design | |
Product color | Schwarz |
housing material | Metall |
LED indicators | Aktivität, Link, Leistung |
Services | |
energy | |
energy source | AC |
AC input voltage | 100 - 240 V |
output voltage | 52 V |
output current | 2,3 A |
Power Over Ethernet (PoE) | |
Number of Power over Ethernet (PoE) ports | 8 |
Number of Power over Ethernet plus (PoE+) ports | 8 |
Power over Ethernet (PoE) performance per port | 30 W |
Overall Power over Ethernet (PoE) | 120 W |
Other functions | |
bandwidth | 20 Gbit/s |
operating conditions | |
operating temperatur | -20 - 50 °C |
Storage temperature range | -40 - 80 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 90% |
weight and dimensions | |
broad | 222 mm |
depth | 163 mm |
height | 40 mm |
scope of delivery | |
Supplied cables | AC |
