management functions | |
Switch-Typ | Managed |
switch level | L2/L3 |
Eigenschaft | Rackmontageset |
MIB support | RFC2925, RFC2618, RFC2620, RFC2021, RFC2819, RFC2674, RFC1493, RFC1643, RFC2233, RFC1213 |
connections and interfaces | |
Quantity of module slots SFP+ | 8 |
console port | RJ-45/micro-USB |
power plug | DC-Anschluss |
network | |
mesh standard | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad, IEEE 802.3x |
Virtual LAN functions | Private VLAN, Protocol-based VLAN, Voice VLAN |
Number of VLANs | 4000 |
data transmission | |
Routing/Switching Capacity | 160 Gbit/s |
Transferrate | 119,04 Mpps |
MAC-Adressentabelle | 32000 Eintragungen |
number of queues | 8 |
Jumbo-Frames | 9000 |
Data packet buffer memory | 16 MB |
safety | |
DHCP functions | DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 snooping |
Supported security algorithms | HTTPS, SSH, SSH-2, SSL/TLS |
authentication | Gast VLAN, MAC-basierte Authentifizierung, Port-basierte Authentifizierung, Webbasierte Authentifizierung |
authentication type | AAA, TACACS+ |
Queue Scheduling Algorithms | SP, WRR+SP, Weighted Round Robin (WRR) |
multicast capabilities | |
logs | |
management logs | SNMPv1/v2c/v3, SNTP |
IPv4 & IPv6 features | IPv6 Telnet, IPv6 ping, IPv6 tracert |
Design | |
Product color | Schwarz |
certification | CE, FCC, RoHS |
energy | |
energy source | AC |
AC input voltage | 220 V |
AC input frequency | 50/60 Hz |
Power consumption (max.) | 15,46 W |
operating conditions | |
operating temperatur | 0 - 45 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 90% |
heat dissipation | 52,75 BTU/h |
weight and dimensions | |
broad | 440 mm |
depth | 180 mm |
height | 44 mm |
Supplied cables | AC |
packaging type | Box |
