management functions | |
Switch-Typ | Unmanaged |
Eigenschaft | Benutzerhandbuch |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 8 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Number of Gigabit Ethernet (copper) ports | 8 |
power plug | DC-Anschluss |
network | |
mesh standard | IEEE 802.1p, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
Ethernet LAN data transfer rates | 10,100,1000 Mbit/s |
data transmission | |
data rate | 10/100/1000Mbps |
Routing/Switching Capacity | 16 Gbit/s |
Transferrate | 11,9 Mpps |
MAC-Adressentabelle | 4000 Eintragungen |
Max. data transfer rate | 2 Gbit/s |
Jumbo-Frames | 16000 |
Data packet buffer memory | 1,5 MB |
safety | |
logs | |
Switch Protokoll | CSMA/CD |
Design | |
Product color | Schwarz |
energy | |
energy source | Gleichstrom |
input current | 0.6 A |
input voltage | 9 V |
Power consumption (max.) | 3,31 W |
Other functions | |
transmission technology | Kabelgebunden |
bandwidth | 16 Gbit/s |
packet transmission speed | 14880pps/148800pps/1488000pps |
Ethernet interfaces type | Gigabit Ethernet |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 90% |
weight and dimensions | |
broad | 158 mm |
depth | 101 mm |
height | 25 mm |
scope of delivery | |
package weight | 510 g |
certificates | |
certification | CE, FCC, RoHS |
logistic data | |
Goods tariff number (HS) | 85176990 |
