management functions | |
Switch-Typ | Managed |
switch level | L2 |
Eigenschaft | Betriebsanleitung |
MIB support | RFC 1213 MIB II, RFC 2819, RFC 1215, RFC 1493 |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 8 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Number of Gigabit Ethernet (copper) ports | 8 |
power plug | AC-Eingangsbuchse |
network | |
mesh standard | IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
Copper Ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
Number of VLANs | 8 |
data transmission | |
Routing/Switching Capacity | 16 Gbit/s |
Transferrate | 11,9 Mpps |
MAC-Adressentabelle | 8000 Eintragungen |
Jumbo-Frames | 9000 |
Data packet buffer memory | 0,525 MB |
safety | |
multicast capabilities | |
logs | |
management logs | SNMP v1,v2,v3, RMON (1,2,3,9) |
Design | |
Product color | Schwarz |
Electromagnetic compatibility | LVD EN60950-1, BSMI CNS14336-1 |
certification | CE, FCC, C-Tick, Class A, Class B, BSMI CNS13438 |
Services | |
Mean Time Between Failures (MTBF) | 1144461 h |
energy | |
energy source | AC |
AC input voltage | 220 - 240 V |
AC input frequency | 50 - 60 Hz |
Power consumption (max.) | 4,7 W |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 95% |
humidity during storage | 10 - 95% |
heat dissipation | 16,03 BTU/h |
weight and dimensions | |
broad | 250 mm |
depth | 104 mm |
height | 27 mm |
Weight | 620 g |
Supplied cables | AC |
package weight | 1,1 kg |
logistic data | |
Goods tariff number (HS) | 85176990 |
