management functions | |
Switch-Typ | Managed |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 8 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Number of installed SFP modules | 2 |
network | |
mesh standard | IEEE 802.3af, IEEE 802.3at |
Eigenschaft | Nachhaltigkeitskonformität |
data transmission | |
Routing/Switching Capacity | 56 Gbit/s |
safety | |
Design | |
Product color | Weiß |
International degree of protection (IP code) | IP20 |
Services | |
Installed operating system | SwitchOS Lite |
processor | Marvell 88E6193X |
Flash memory | 0,064 MB |
Mean Time Between Failures (MTBF) | 200000 h |
energy | |
energy source | AC/DC |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
DC input voltage | 48 - 57 V |
input current | 2.2 A |
Power consumption (max.) | 162 W |
Power Over Ethernet (PoE) | |
Power over Ethernet (PoE) type supported | Passive PoE |
Number of Power over Ethernet (PoE) ports | 8 |
Overall Power over Ethernet (PoE) | 140 W |
operating conditions | |
Storage temperature range | -40 - 70 °C |
weight and dimensions | |
broad | 272 mm |
depth | 216 mm |
height | 50 mm |
scope of delivery | |
Supplied cables | AC |
sustainability | |
certificates | |
Konformitätsbescheinigungen | CE, RoHS |
certification | EAC |
