management functions | |
Switch-Typ | Unmanaged |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 16 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Number of Gigabit Ethernet (copper) ports | 16 |
network | |
mesh standard | IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
Eigenschaft | LED-Anzeigen |
data transmission | |
Routing/Switching Capacity | 32 Gbit/s |
passage | 23,8 Mpps |
MAC-Adressentabelle | 8000 Eintragungen |
Jumbo-Frames | 10000 |
Packet water supply system (1 Gbit / s) | 1488000 pps |
Packetweiterleitungsrate (100 Mbit / s) | 148800 pps |
Packetweiterleitungsrate (10 Mbit / s) | 14880 pps |
Data packet buffer memory | 0,524 MB |
safety | UL60950-1, 2nd Edition, CSA C22.2 No.60950-1-07, 2nd Edition, IEC60950-1(UL-EU, UL-CB) |
Supported security algorithms | EAP |
Design | |
Product color | Grau |
energy | |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
input current | 0.3 A |
Power consumption (max.) | 12 W |
operating conditions | |
operating temperatur | 0 - 50 °C |
weight and dimensions | |
broad | 263 mm |
depth | 179 mm |
height | 38 mm |
Weight | 1,5 kg |
certificates | |
certification | EAC, EN55024, ICES Class A, VCCI Class A, FCC Class A, RCM, CE, EN55022, CISPR 55022 |
