management functions | |
Switch-Typ | Unmanaged |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 5 |
Basic Switching RJ-45 Ethernet Ports-Typ | Fast Ethernet (10/100) |
network | |
mesh standard | IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
Eigenschaft | Wandmontage |
data transmission | |
Routing/Switching Capacity | 1 Gbit/s |
passage | 0,74 Mpps |
MAC-Adressentabelle | 2000 Eintragungen |
Jumbo-Frames | 2048 |
Data packet buffer memory | 0,096 MB |
Design | |
Product color | Grün, Grau |
LED indicators | Aktivität, Link, Leistung |
safety | UL60950-1, CSAC22.2 №60950-1, EN60950-1(TUV), CE |
energy | |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Power consumption (max.) | 1,7 W |
operating conditions | |
operating temperatur | 0 - 50 °C |
Storage temperature range | -20 - 70 °C |
Operating relative humidity | 5 - 90% |
humidity during storage | 5 - 95% |
weight and dimensions | |
broad | 131 mm |
depth | 101 mm |
height | 30 mm |
Weight | 380 g |
certificates | |
certification | VCCI Class BFCC Class BEN55032 Class ACISPR 32 Class BRCM Class B |
logistic data | |
Goods tariff number (HS) | 85176990 |
