| management functions | |
| Switch-Typ | Managed |
| switch level | L3 |
| Eigenschaft | Nachhaltigkeitskonformität |
| connections and interfaces | |
| Number of basic switching RJ-45 Ethernet ports | 20 |
| Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
| Number of Gigabit Ethernet (copper) ports | 24 |
| Number of installed SFP modules | 4 |
| console port | USB |
| network | |
| Copper Ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Ethernet LAN data transfer rates | 10,100,1000,2500,5000 Mbit/s |
| Virtual LAN functions | Port-based VLAN, Private VLAN, Tagged VLAN, Voice VLAN |
| Number of VLANs | 4094 |
| data transmission | |
| Routing/Switching Capacity | 160 Gbit/s |
| Transferrate | 119 Mpps |
| MAC-Adressentabelle | 16000 Eintragungen |
| number of queues | 8 |
| Jumbo-Frames | 10000 |
| Data packet buffer memory | 1,5 MB |
| safety | |
| DHCP functions | DHCP Option 82, DHCP relay, DHCP snooping, DHCPv6 client, DHCPv6 relay |
| Supported security algorithms | 3DES, AES, MD5, SHA-1, SHA-2, SHA-256, SHA-384, SHA-512, SSH, SSH-2, SSL/TLS |
| authentication | MAC-basierte Authentifizierung, Port-basierte Authentifizierung, Webbasierte Authentifizierung |
| Queue Scheduling Algorithms | SP, WRR+SP, Weighted Round Robin (WRR) |
| multicast capabilities | |
| logs | |
| management logs | SNMPv1, v2c, v3 |
| Router protocol | RIP, RIP-2, RIPng |
| Design | |
| form factor | 1U |
| Product color | Grau |
| Services | |
| Physical Stacking (Units) | 2 |
| storage type | DDR3-SDRAM |
| storage capacity | 1000 MB |
| Flash memory | 256 MB |
| noise level | 42 dB |
| energy | |
| Power consumption (standard operation) | 70 W |
| Power consumption (max.) | 510 W |
| Power Over Ethernet (PoE) | |
| Number of Power over Ethernet plus (PoE+) ports | 24 |
| Power over Ethernet (PoE) performance per port | 30 W |
| Overall Power over Ethernet (PoE) | 370 W |
| operating conditions | |
| operating temperatur | 0 - 50 °C |
| Storage temperature range | -25 - 70 °C |
| Operating relative humidity | 5 - 90% |
| humidity during storage | 5 - 95% |
| operating height | 0 - 3000 m |
| heat dissipation | 1741 BTU/h |
| weight and dimensions | |
| broad | 441 mm |
| depth | 421 mm |
| height | 44 mm |
| Weight | 5,6 kg |
| package weight | 7,6 kg |
| sustainability | |
| certificates | |
| Konformitätsbescheinigungen | RoHS, cTUVus |
