management functions | |
Switch-Typ | Managed |
switch level | L3 |
Eigenschaft | Power over Ethernet (PoE) |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 12 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Quantity of module slots SFP+ | 2 |
console port | RJ-45/USB Type-C |
network | |
Number of VLANs | 4094 |
data transmission | |
Routing/Switching Capacity | 68 Gbit/s |
passage | 45,1 Mpps |
Latency (1Gbps) | 2,28 µs |
Latency (10 Gbps) | 1,46 µs |
safety | |
DHCP functions | DHCP server |
authentication type | RADIUS, TACACS+ |
multicast capabilities | |
logs | |
Router protocol | OSPF, OSPFv2, OSPFv3, RIP-2, RIPng |
IPv4 & IPv6 features | IPv4/IPv6 access-control list (ACL) |
Design | |
form factor | 1U |
Services | |
Virtual Stacking (Units) | 8 |
processor | ARM Cortex-A72 |
processor clock speed | 1200 MHz |
energy | |
energy source | AC |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Power consumption (standard operation) | 170 W |
Power Over Ethernet (PoE) | |
Overall Power over Ethernet (PoE) | 139 W |
operating conditions | |
operating temperatur | 0 - 45 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 5 - 95% |
humidity during storage | 5 - 95% |
weight and dimensions | |
broad | 442,5 mm |
depth | 325,4 mm |
height | 43,9 mm |
Weight | 5,09 kg |
