management functions | |
Switch-Typ | Managed |
switch level | L3 |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 24 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Number of installed SFP modules | 4 |
console port | RJ-45/USB Type-C |
network | |
mesh standard | IEEE 802.3af, IEEE 802.3at |
Eigenschaft | Power over Ethernet (PoE) |
data transmission | |
Routing/Switching Capacity | 176 Gbit/s |
passage | 95,2 Mpps |
MAC-Adressentabelle | 32000 Eintragungen |
Data packet buffer memory | 8 MB |
Design | |
Services | |
processor | ARM Cortex-A72 |
processor clock speed | 1,8 MHz |
storage type | DDR4-SDRAM |
storage capacity | 8192 MB |
Flash memory | 16000 MB |
energy | |
energy source | AC |
AC input voltage | 100 - 240 V |
Power consumption (standard operation) | 76 W |
Power Over Ethernet (PoE) | |
Power over Ethernet (PoE) performance per port | 30 W |
Overall Power over Ethernet (PoE) | 740 W |
weight and dimensions | |
broad | 442,5 mm |
depth | 383,8 mm |
height | 43,9 mm |
Weight | 6,01 kg |
