management functions | |
Switch-Typ | Managed |
switch level | L2/L3 |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 40 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Quantity of module slots SFP+ | 8 |
Number of USB 2.0 ports | 1 |
network | |
mesh standard | IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt |
Eigenschaft | Ablageschienen |
data transmission | |
Routing/Switching Capacity | 240 Gbit/s |
passage | 178,56 Mpps |
MAC-Adressentabelle | 16000 Eintragungen |
Latency (1Gbps) | 2,78 µs |
Latency (10 Gbps) | 0,73 µs |
Design | |
form factor | 2U |
Product color | Schwarz |
Services | |
noise level | 60 dB |
energy | |
Power consumption (standard operation) | 912 W |
Power Over Ethernet (PoE) | |
Power over Ethernet (PoE) type supported | Active PoE |
Number of Power over Ethernet plus (PoE+) ports | 40 |
Overall Power over Ethernet (PoE) | 2880 W |
operating conditions | |
heat dissipation | 3113,57 BTU/h |
weight and dimensions | |
broad | 440 mm |
depth | 86,4 mm |
height | 350 mm |
Weight | 10,3 kg |
scope of delivery | |
Supplied cables | LAN (RJ-45), USB Typ-C |
logistic data | |
Goods tariff number (HS) | 85176990 |
