Certification | UL (UL 60950), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A, FCC Class B |
Form factor | 1U |
Product colour | Grey |
LED indicators | Yes |
Rack mounting | Yes |
Power supply included | Yes |
Redundant power supply (RPS) support | No |
Number of power supply units | 1 |
DC input voltage | 12 V |
Queue scheduling algorithms | Weighted Round Robin (WRR) |
Storage temperature (T-T) | -20 - 70 °C |
Operating temperature (T-T) | 0 - 40 °C |
Operating relative humidity (H-H) | 10 - 90% |
Storage relative humidity (H-H) | 5 - 90% |
Heat dissipation | 9.34 BTU/h |
Quality of Service (QoS) support | Yes |
Switch layer | L2 |
Switch type | Unmanaged |
Weight | 230 g |
Width | 110 mm |
Depth | 75 mm |
Height | 30 mm |
Full duplex | Yes |
Networking standards | IEEE 802.3 |
Auto MDI/MDI-X | Yes |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Copper ethernet cabling technology | 10BASE-T |
Half duplex | Yes |
Head-of-line (HOL) blocking | Yes |
10G support | No |
Flow control support | Yes |
Mean time between failures (MTBF) | 4243002 h |
Quick start guide | Yes |
Gigabit Ethernet (copper) ports quantity | 5 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 5 |
Harmonized System (HS) code | 85176990 |
Switching capacity | 10 Gbit/s |
Forwarding rate | 7.4 Mpps |
Number of queues | 4 |
MAC Address Table | 2048 entries |
Jumbo Frames support | Yes |
Jumbo frames | 9216 |
Power Over Ethernet (PoE) | No |
