Product colour | Grey |
Power consumption (max) | 14.9 W |
Input current | 0.22 A |
Power supply included | Yes |
AC input voltage | 110 - 240 V |
AC input frequency | 50 - 60 Hz |
Power consumption (typical) | 14.2 W |
IGMP snooping | Yes |
IGMP entries | 1024 |
Loop protection | Yes |
BPDU filtering/protection | Yes |
DHCP features | DHCP snooping |
SSH/SSL support | Yes |
Authentication type | RADIUS |
Access Control List (ACL) | Yes |
Authentication | Web-based authentication |
Storage temperature (T-T) | -25 - 70 °C |
Operating altitude | 0 - 3000 m |
Storage relative humidity (H-H) | 5 - 95% |
Operating relative humidity (H-H) | 5 - 90% |
Operating temperature (T-T) | -5 - 50 °C |
Non-operating altitude | 0 - 4500 m |
ARP inspection | Yes |
Quality of Service (QoS) support | Yes |
Configuring Location Settings (CLI) | Yes |
Web-based management | Yes |
Traffic classification | Yes |
MIB support | Y |
Switch layer | L2 |
Switch type | Managed |
Networking standards | IEEE 802.1w |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Link aggregation | Yes |
VLAN support | Yes |
Broadcast storm control | Yes |
Spanning tree protocol | Yes |
Auto-negotiation | Yes |
Full duplex | Yes |
Auto MDI/MDI-X | Yes |
Processor frequency | 800 MHz |
Memory type | DRAM |
Built-in processor | Yes |
Flash Memory | 256 MB |
Processor model | ARM7 |
Mean time between failures (MTBF) | 2171669 h |
INTERNAL MEMORY | 512 MB |
Package depth | 349.2 mm |
Package width | 309.6 mm |
PACKAGE WEIGHT | 2.59 kg |
Package height | 160.3 mm |
Management protocols | SNMP |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 8 |
USB 2.0 ports quantity | 1 |
Combo SFP ports quantity | 2 |
Dimensions (W x D x H) (imperial) | 268.2 x 184.9 x 43.9 mm (10.6 x 7.28 x 1.73") |
Quantity per pack | 1 pc(s) |
Harmonized System (HS) code | 85176990 |
Jumbo Frames support | Yes |
Forwarding rate | 10000 Mpps |
Jumbo frames | 10240 |
MAC Address Table | 15360 entries |
Switching capacity | 20 Gbit/s |
Static route | Yes |
Multicast support | Yes |
IPv4 multicast entries | 1024 |
