Product Description | Cisco Catalyst 9200L - Network Essentials - switch - 48 ports - Managed - rack-mountable |
Device type | Switch - 48 ports - L3 - Managed |
Enclosure Type | Rack-mountable |
Subtype | Gigabit Ethernet |
Ports | 48 x 10/100/1000 (PoE+) + 4 x 10 Gigabit SFP+ |
Power Over Ethernet (PoE) | PoE+ |
Performance | Stacking bandwidth: 80 Gbps
Switching capacity: 176 Gbps
Forwarding rate: 261.9 Mpps |
Capacity | Virtual networks: 1
MAC addresses: 16000
IPv4 routes: 11000
IPv4 routing table entries: 3000
IPv6 routing table entries: 1500
Multicast scale: 1000
ACL scale entries: 1500
FNF entries: 16000
Switched virtual interfaces (SVIs): 512
Queues per port (egress): 8 |
Jumbo Frame Support | 9198 bytes |
Routing Protocol | OSPF, RIP, VRRP, policy-based routing (PBR), MSTP |
Remote Management Protocol | SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, NETCONF, RESTCONF |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3at, IEEE 802.3bz |
Power | AC 100-240 V - power supply not installed |
Dimensions (WxDxH) | 44.5 cm x 4.4 cm x 28.8 cm |
Weight | 5.5 kg |
Manufacturer Warranty | Limited lifetime warranty |
