Product Description | Cisco Catalyst 9500 - Network Essentials - switch - 16 ports - Managed - rack-mountable |
Device type | Switch - 16 ports - L3 - Managed |
Enclosure Type | Rack-mountable 1U |
Subtype | 10 Gigabit Ethernet |
Ports | 16 x 10 Gigabit Ethernet + 2 x 10 Gigabit SFP+ |
Performance | Switching capacity (full duplex): up to 480 Gbps
Forwarding rate: up to 360 Mpps |
Capacity | Indirect IPv4 routes: 64000
Host IPv4 routes: 80000
Indirect IPv6 routes: 32000
Host IPv6 routes: 40000
Multicast scale: 16000
QoS ACL scale: 18000
Security ACL scale: 18000
FNF entries: 512000
VLAN IDs: 4000
Switched virtual interfaces (SVIs): 4000 |
MAC Address Table Size | 64K entries |
Jumbo Frame Support | 9198 bytes |
Routing Protocol | OSPF, RIP-1, RIP-2, IGMP, VRRP, PIM-SM, PIM-SSM, policy-based routing (PBR), RIPng |
Remote Management Protocol | SNMP 1, RMON 1, RMON 2, SNMP, SNMP 3, SNMP 2c, TFTP, NETCONF, RESTCONF |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ae |
Power | AC 120/230 V (50 - 60 Hz) |
Power Redundancy | Yes |
Dimensions (WxDxH) | 4.39 cm x 44.5 cm x 54.7 cm |
Weight | 10.7 kg |
Manufacturer Warranty | Limited lifetime warranty |
