management functions | |
Switch-Typ | Managed |
switch level | L2/L3 |
Eigenschaft | Rack-Einbau |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 24 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Number of Gigabit Ethernet (copper) ports | 2 |
Quantity of module slots SFP+ | 24 |
console port | RS-232 |
Number of USB 2.0 ports | 2 |
network | |
Virtual LAN functions | Private VLAN, Tagged VLAN |
Number of VLANs | 4096 |
data transmission | |
Routing/Switching Capacity | 480 Gbit/s |
passage | 360 Mpps |
MAC-Adressentabelle | 64000 Eintragungen |
Jumbo-Frames | 9216 |
Data packet buffer memory | 18 MB |
safety | |
multicast capabilities | |
logs | |
management logs | SSHv2, SNMP v1/v2/v3, RADIUS, TACACS+ |
Supported network protocols | IPv4, IPv6 |
Design | |
form factor | 1U |
Product color | Grau |
Services | |
Flash memory | 2048 MB |
Mean Time Between Failures (MTBF) | 317030 h |
energy | |
Number of power supply units | 2 |
AC input voltage | 100 - 240 V |
Power consumption (standard operation) | 102 W |
Power consumption (max.) | 193 W |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 85% |
humidity during storage | 5 - 95% |
operating height | 0 - 3000 m |
heat dissipation | 904 BTU/h |
weight and dimensions | |
broad | 439 mm |
depth | 467 mm |
height | 43,6 mm |
Weight | 7,9 kg |
