Wall mountable | Yes |
LED indicators | Power |
Housing material | Metal |
Product colour | Black |
Rack mounting | Yes |
Power source | AC |
Output voltage | 52 V |
Input current | 1.25 A |
AC input voltage | 100 - 240 V |
Output current | 1.25 A |
Power supply included | Yes |
Storage relative humidity (H-H) | 5 - 90% |
Operating relative humidity (H-H) | 10 - 90% |
Operating temperature (T-T) | -20 - 50 °C |
Operating altitude | 0 - 3048 m |
Storage temperature (T-T) | -40 - 85 °C |
Height | 44 mm |
Depth | 118 mm |
Weight | 600 g |
Width | 200 mm |
Half duplex | Yes |
Networking standards | IEEE 802.3 |
Cable types supported | Cat8 |
Full duplex | Yes |
Flow control support | Yes |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
VLAN support | Yes |
Copper ethernet cabling technology | 1000BASE-TX |
Fanless | Yes |
Mean time between failures (MTBF) | 100000 h |
Plug and Play | Yes |
PACKAGE WEIGHT | 900 g |
Package depth | 190 mm |
CABLES INCLUDED | AC |
Package width | 245 mm |
Package Type | Box |
Manual | Yes |
Package height | 60 mm |
Uplink ports quantity | 1 |
Combo SFP ports quantity | 1 |
Installed SFP modules quantity | 1 |
Power connector | AC-in jack |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 5 |
Master (outer) case width | 505 mm |
Master (outer) case length | 320 mm |
Products per master (outer) case | 20 pc(s) |
Master (outer) case net weight | 19 kg |
Master (outer) case height | 402 mm |
Packet buffer memory | 1 MB |
Store-and-forward | Yes |
Jumbo frames | 9216 |
MAC Address Table | 2000 entries |
Switching capacity | 12 Gbit/s |
Jumbo Frames support | Yes |
Throughput | 8.928 Mpps |
Total Power over Ethernet (PoE) budget | 120 W |
Power Over Ethernet (PoE) | Yes |
Power over Ethernet plus (PoE+) ports quantity | 1 |
Power over Ethernet (PoE) power per port | 30 W |
Power over Ethernet (PoE) ports quantity | 4 |
Switching optical modules type | Gigabit Ethernet |
Fiber type | Multi-mode |
