Rack mounting | No |
LED indicators | Link |
Product colour | Black |
Power supply included | Yes |
DC input voltage | 5 V |
Power consumption (max) | 2.3 W |
Input current | 1 A |
Power source | DC |
Operating temperature (T-T) | 0 - 40 °C |
Operating relative humidity (H-H) | 10 - 90% |
Storage relative humidity (H-H) | 5 - 95% |
Storage temperature (T-T) | -40 - 70 °C |
Depth | 72.7 mm |
Height | 26.9 mm |
Width | 143 mm |
Weight | 215 g |
Full duplex | Yes |
Auto MDI/MDI-X | Yes |
Copper ethernet cabling technology | 1000BASE-T |
MAC address auto-learning supported | Yes |
Cable types supported | Cat5 |
Flow control support | Yes |
Auto-negotiation | Yes |
Half duplex | Yes |
MAC address auto-aging supported | Yes |
Networking standards | IEEE 802.3az |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Plug and Play | Yes |
Manual | Yes |
CABLES INCLUDED | DC |
Package Type | Box |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 8 |
Bandwidth | 1.6 Gbit/s |
Store-and-forward | Yes |
Packet forwarding rate (100 Mbps) | 148800 pps |
Packet forwarding rate (10 Mbps) | 14880 pps |
Packet forwarding rate (1 Gbps) | 1488000 pps |
Switching capacity | 16 Gbit/s |
Power Over Ethernet (PoE) | No |
