LED indicators | Yes |
Product colour | Black |
Housing material | Metal |
DC input voltage | 48 - 57 V |
Operating relative humidity (H-H) | 10 - 90% |
Operating temperature (T-T) | -10 - 55 °C |
Switch type | Unmanaged |
Switch layer | L2 |
Height | 30 mm |
Weight | 490 g |
Depth | 100 mm |
Width | 190 mm |
Copper ethernet cabling technology | 100BASE-TX |
Networking standards | IEEE 802.3 |
10G support | No |
MAC address auto-learning supported | Yes |
Flow control support | Yes |
MAC address auto-aging supported | Yes |
Auto MDI/MDI-X | Yes |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 8 |
Gigabit Ethernet (copper) ports quantity | 8 |
Forwarding rate | 11.9 Mpps |
MAC Address Table | 8000 entries |
Switching capacity | 20 Gbit/s |
Power Over Ethernet (PoE) | Yes |
