Reset button | Yes |
Rack mounting | Yes |
Housing material | Metal |
Product colour | Black |
Power consumption (typical) | 265 W |
AC input voltage | 100 - 240 V |
Power supply included | Yes |
AC input frequency | 47/63 Hz |
Power source | AC/DC/PoE |
Loop protection | Yes |
DHCP features | DHCP client |
Operating relative humidity (H-H) | 5 - 95% |
Operating temperature (T-T) | -10 - 55 °C |
Storage relative humidity (H-H) | 5 - 95% |
Storage temperature (T-T) | -40 - 70 °C |
Switch layer | L2 |
Cloud-managed | Yes |
Switch type | Managed |
Web-based management | Yes |
Height | 44 mm |
Width | 440 mm |
Depth | 220 mm |
Weight | 2.37 kg |
Spanning tree protocol | Yes |
Networking standards | IEEE 802.3bt |
VLAN support | Yes |
Number of VLANs | 32 |
Flow control support | Yes |
10G support | No |
PACKAGE WEIGHT | 3.02 kg |
Package width | 540 mm |
Package height | 90 mm |
Package depth | 342 mm |
Basic switching RJ-45 Ethernet ports quantity | 18 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
SFP module slots quantity | 2 |
Jumbo frames | 15360 |
Forwarding rate | 29.76 Mpps |
Switching capacity | 40 Gbit/s |
Jumbo Frames support | Yes |
MAC Address Table | 8000 entries |
Power over Ethernet (PoE) ports quantity | 16 |
Power Over Ethernet (PoE) | Yes |
Total Power over Ethernet (PoE) budget | 240 W |
