Reset button | Yes |
Wall mountable | Yes |
LED indicators | Yes |
Housing material | Metal |
Product colour | Black |
Input current | 1.226 A |
DC input voltage | 53 V |
Power consumption (max) | 65 W |
Power source | DC |
DHCP features | DHCP client |
Operating relative humidity (H-H) | 5 - 95% |
Operating temperature (T-T) | -10 - 55 °C |
Storage relative humidity (H-H) | 5 - 95% |
Storage temperature (T-T) | -40 - 70 °C |
Switch type | Managed |
Cloud-managed | Yes |
Quality of Service (QoS) support | Yes |
Web-based management | Yes |
Switch layer | L2 |
Width | 130 mm |
Depth | 90 mm |
Height | 26 mm |
Weight | 290 g |
Networking standards | IEEE 802.3x |
Copper ethernet cabling technology | 10BASE-T |
VLAN support | Yes |
Link aggregation | Yes |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Spanning tree protocol | Yes |
Full duplex | Yes |
Number of VLANs | 32 |
Flow control support | Yes |
10G support | No |
Virtual LAN features | Port-based VLAN |
Package height | 76 mm |
PACKAGE WEIGHT | 940 g |
Package width | 265 mm |
Package depth | 238 mm |
Basic switching RJ-45 Ethernet ports quantity | 6 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Gigabit Ethernet (copper) ports quantity | 6 |
MAC Address Table | 8000 entries |
Switching capacity | 12 Gbit/s |
Jumbo Frames support | Yes |
Forwarding rate | 8.93 Mpps |
Jumbo frames | 15000 |
Power Over Ethernet (PoE) | Yes |
Power over Ethernet (PoE) ports quantity | 4 |
