Compliance certificates | CE |
LED indicators | Yes |
Rack mounting | No |
Reset button | Yes |
Product colour | Black |
Housing material | Metal |
DC input voltage | 54 V |
Power source | DC/PoE |
Input current | 2.22 A |
Redundant power supply (RPS) support | Yes |
Power supply included | Yes |
Power consumption (max) | 110 W |
DHCP features | DHCP client |
Operating relative humidity (H-H) | 5 - 95% |
Storage temperature (T-T) | -40 - 70 °C |
Storage relative humidity (H-H) | 5 - 95% |
Operating temperature (T-T) | -10 - 55 °C |
Cloud-managed | Yes |
Quality of Service (QoS) support | Yes |
Web-based management | Yes |
Switch layer | L2 |
Switch type | Managed |
Depth | 106 mm |
Height | 30 mm |
Weight | 550 g |
Width | 190 mm |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Virtual LAN features | Port-based VLAN |
Spanning tree protocol | Yes |
Networking standards | IEEE 802.3at |
Copper ethernet cabling technology | 100BASE-TX |
VLAN support | Yes |
Number of VLANs | 32 |
Flow control support | Yes |
10G support | No |
PACKAGE WEIGHT | 1.3 kg |
Package height | 87 mm |
Package width | 256 mm |
Package depth | 244 mm |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Gigabit Ethernet (copper) ports quantity | 10 |
Basic switching RJ-45 Ethernet ports quantity | 10 |
MAC Address Table | 8000 entries |
Packet buffer memory | 0.5 MB |
Jumbo Frames support | Yes |
Switching capacity | 20 Gbit/s |
Forwarding rate | 4.17 Mpps |
Jumbo frames | 15000 |
Power over Ethernet (PoE) ports quantity | 8 |
Power Over Ethernet (PoE) | Yes |
Sustainability compliance | Yes |
