Product colour | Black |
Rack mounting | Yes |
Housing material | Metal |
Power consumption (max) | 265 W |
Power source | AC |
Power supply included | Yes |
DHCP features | DHCP client |
Storage temperature (T-T) | -40 - 70 °C |
Operating temperature (T-T) | -10 - 55 °C |
Operating relative humidity (H-H) | 5 - 95% |
Storage relative humidity (H-H) | 5 - 95% |
Switch layer | L2 |
Web-based management | Yes |
Switch type | Managed |
Width | 220 mm |
Height | 44 mm |
Weight | 2.35 kg |
Depth | 440 mm |
10G support | No |
Number of VLANs | 32 |
Networking standards | IEEE 802.3u |
VLAN support | Yes |
Mean time between failures (MTBF) | 763.502 h |
Package depth | 540 mm |
PACKAGE WEIGHT | 3 kg |
Package width | 342 mm |
Package height | 90 mm |
SFP module slots quantity | 2 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 18 |
Gigabit Ethernet (copper) ports quantity | 16 |
Packet buffer memory | 4 MB |
Switching capacity | 7.2 Gbit/s |
Forwarding rate | 5.36 Mpps |
MAC Address Table | 8000 entries |
Jumbo Frames support | Yes |
Jumbo frames | 15000 |
Power Over Ethernet (PoE) | Yes |
Total Power over Ethernet (PoE) budget | 240 W |
Power over Ethernet (PoE) power per port | 30 W |
