Housing material | Metal |
Product colour | Black |
LED indicators | Yes |
Rack mounting | No |
Wall mountable | Yes |
DC input voltage | 48 - 57 V |
Power consumption (max) | 60 W |
Power source | DC/PoE |
Storage relative humidity (H-H) | 5 - 95% |
Storage temperature (T-T) | -20 - 70 °C |
Operating temperature (T-T) | -10 - 55 °C |
Operating relative humidity (H-H) | 5 - 95% |
Switch layer | L2 |
Switch type | Unmanaged |
Depth | 100 mm |
Height | 30 mm |
Width | 190 mm |
Weight | 490 g |
Flow control support | Yes |
10G support | No |
Networking standards | IEEE 802.3u |
Auto MDI/MDI-X | Yes |
Full duplex | Yes |
Copper ethernet cabling technology | 100BASE-TX |
Ethernet LAN data rates | 10,100 Mbit/s |
Compliance certificates | CE |
Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
Basic switching RJ-45 Ethernet ports quantity | 8 |
Fast Ethernet (copper) ports quantity | 8 |
MAC Address Table | 2048 entries |
Packet buffer memory | 0.768 MB |
Switching capacity | 1.8 Gbit/s |
Forwarding rate | 1.19 Mpps |
Power Over Ethernet (PoE) | Yes |
Power over Ethernet (PoE) ports quantity | 4 |
Sustainability compliance | Yes |
