Product colour | Black |
Housing material | Metal |
AC input voltage | 100 - 240 V |
Power source | AC |
Power consumption (max) | 240 W |
MAC address filtering | Yes |
Queue scheduling algorithms | Weighted Round Robin (WRR) |
Authentication | Port-based authentication |
DHCP features | DHCP client |
IP-MAC-Port binding | Yes |
Operating temperature (T-T) | -10 - 55 °C |
Operating relative humidity (H-H) | 10 - 90% |
Switch layer | L2 |
Switch type | Managed |
Quality of Service (QoS) support | Yes |
Depth | 440 mm |
Width | 300 mm |
Height | 44 mm |
Port mirroring | Yes |
Flow control support | Yes |
Networking standards | IEEE 802.3af |
Link aggregation | Yes |
Full duplex | Yes |
Spanning tree protocol | Yes |
Half duplex | Yes |
Plug and Play | Yes |
Package depth | 527 mm |
Package width | 412 mm |
Package height | 110 mm |
Basic switching RJ-45 Ethernet ports quantity | 26 |
console port | RJ-45 |
Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
Gigabit Ethernet (copper) ports quantity | 2 |
Combo SFP ports quantity | 2 |
Fast Ethernet (copper) ports quantity | 24 |
Fiber uplink ports quantity | 2 |
Uplink ports quantity | 2 |
Switching capacity | 8.8 Gbit/s |
MAC Address Table | 4000 entries |
Packet buffer memory | 2.75 MB |
Forwarding rate | 6.55 Mpps |
Power Over Ethernet (PoE) | Yes |
Total Power over Ethernet (PoE) budget | 240 W |
Multicast support | Yes |
