| Product colour | Black |
| LED indicators | Link |
| Rack mounting | Yes |
| Electromagnetic compatibility | CE A, VCCI A, FCC A, IC, BSMI |
| AC input voltage | 100 - 240 V |
| Power consumption (max) | 455.1 W |
| Power supply included | Yes |
| Security algorithms | LEAP |
| DHCP features | DHCP server |
| IGMP snooping | Yes |
| Access Control List (ACL) | Yes |
| Access Control List (ACL) rules | 768 |
| Loop protection | Yes |
| Queue scheduling algorithms | Weighted Round Robin (WRR) |
| IP-MAC-Port binding | Yes |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating temperature (T-T) | -5 - 50 °C |
| Storage relative humidity (H-H) | 0 - 95% |
| Heat dissipation | 1551.891 BTU/h |
| Operating relative humidity (H-H) | 0 - 95% |
| Web-based management | Yes |
| Switch type | Managed |
| Quality of Service (QoS) support | Yes |
| ARP inspection | Yes |
| System event log | Yes |
| Switch layer | L3 |
| Configuring Location Settings (CLI) | Yes |
| Weight | 3.46 kg |
| Depth | 250 mm |
| Height | 44 mm |
| Width | 440 mm |
| Networking standards | IEEE 802.3at |
| Copper ethernet cabling technology | 1000BASE-T |
| Full duplex | Yes |
| Number of VLANs | 4094 |
| 10G support | Yes |
| VLAN support | Yes |
| Port mirroring | Yes |
| Auto MDI/MDI-X | Yes |
| Link aggregation | Yes |
| Broadcast storm control | Yes |
| Spanning tree protocol | Yes |
| Flow control support | Yes |
| Cable types supported | Cat5 |
| Virtual LAN features | Voice VLAN |
| Head-of-line (HOL) blocking | Yes |
| Firmware upgradeable | Yes |
| Memory type | DDR3-SDRAM |
| Flash Memory | 64 MB |
| Noise level | 50.8 dB |
| Mean time between failures (MTBF) | 463430.16 h |
| INTERNAL MEMORY | 2048 MB |
| PACKAGE WEIGHT | 4.76 kg |
| Package depth | 563 mm |
| Package height | 89 mm |
| Package width | 393 mm |
| SFP+ module slots quantity | 4 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| console port | RJ-45 |
| Switching capacity | 128 Gbit/s |
| Jumbo Frames support | Yes |
| Packet buffer memory | 12 MB |
| MAC Address Table | 16000 entries |
| Jumbo frames | 12000 |
| Number of static routes | 124 |
| Store-and-forward | Yes |
| Forwarding rate | 95.24 Mpps |
| Static route | Yes |
| Power Over Ethernet (PoE) | Yes |
| Total Power over Ethernet (PoE) budget | 370 W |
| Power over Ethernet (PoE) power per port | 15.4 W |
| Power over Ethernet (PoE) ports quantity | 24 |
| Multicast support | Yes |
| Fiber ethernet cabling technology | 1000BASE‑SX |
